滑块逆向-FK滑块逆向

请求流程分析

https://i.fkw.com/?_ta=207

首先是一个get请求，参数里有bsskey和bss，返回一个base64编码的字符串imgId


滑动滑块的过程数据包如下，带有bsskey参数和vi参数

vi就是轨迹验证参数，一般是x，y，date，等等组合的数据，后端会校验vi是否是正常轨迹，如果通过则会返回checksign

后续会带上checksign去登录

图片请求

请求的base64解码之后的图片直接就是完整图片，不需要还原

现在就是去分析bsskey参数，通过函数栈在e.registerWithLogger下断点

断下来之后直接看函数栈就行，或者跟一下也行，可以发现在_initCaptchaComp函数中，bsskey是一个被固定的值

import requests
from base64 import b64decode

url='https://cv.fkw.com/verify/get'
data={"bss":4,
      "bssKey":"ALihhLoGCAEQBBoHWzEsMyw1XSIJ6ZKf55Sz5qC5",
      "appKey":1,
      "version":"1.0.1"}
headers={
    'User-Agent': 'Mozilla/5.0 (Windows NT 10.0; Win64; x64) AppleWebKit/537.36 (KHTML, like Gecko) Chrome/111.0.0.0 Safari/537.36 Edg/111.0.1661.54',
    'Accept': 'application/json'
}
html=requests.post(url,headers=headers,json=data).json()
if html['success']:
    bs64img=html['msg']['imgId']
else:
    print('请求图片失败，原因如下：',html['msg'])

with open('fkimg.png','wb')as f:
    f.write(b64decode(bs64img))
    print('FK图片保存成功')

轨迹vi参数生成

在validate请求上的函数栈打下断点，断在t.exports函数处

断下来之后再去看函数栈，跟到e.validateWithLogger的时候发现参数还是加密的，说明加密的函数还在前面

往上找到匿名函数，可以发现这里参数是没加密的，可能加密逻辑就在这里，在匿名函数处下断点

w.on("validate", (function(t) {
    var n = (0,
             u.encrypt)((0,
                         o.default)({}, t, {
        eo: x, //eo的值是前面get请求图片的时候返回
        bss: v, //前面get请求图片的时候返回
        bssKey: g,//固定值
        validateSign: b//前面get请求图片的时候返回
    }));

通过查看变量可以发现，此时t变量是明文，n是加密之后的参数，所以加密逻辑在这里

先解释一下t里面的各个参数的含义

downY是鼠标按下的时候，鼠标距离浏览器上端的距离，upY是鼠标抬起的时候，鼠标距离浏览器下端的距离，这两个参数一般不用在意，固定一个值就行

left是滑块滑动了多少距离，这个和滑块缺口有关

track值如下

track怎么生成的呢？既然这里有w.on("validate", (function(t)监听事件，那么肯定在前面有触发这个信号的

继续往上追函数栈可以发现，e.emit函数触发了validate信号

先看段代码，包含了几个参数

e.emit("validate", {
    left: m(),
    downY: f,
    upY: i,
    track: c
}),

这里的left参数的值是m()函数返回的，m()函数就是返回滑块滑动的距离，这里不再赘述

c的生成逻辑如下

n._bindEvent = function(t) {
    var e = this
    , n = []
    , r = (0,
           l.throttle)((function(t) {
        n.length < 20 ? n.push([t.clientX, t.clientY, (new Date).getTime(), 0, 0]) : l.EventHandler.off(document, "mousemove", r)
    }
                       ), 500);
    ...
    return function(t) {
        c.length < 40 && c.push([t.clientX, t.clientY, (new Date).getTime(), 1, 1]),
            ...
    }(t),
        [function(t) {
            c.length < 40 && c.push([t.clientX, t.clientY, (new Date).getTime(), 2, 1]),
                ...
        }
                , function(t) {
                    c.length < 40 && c.push([t.clientX, t.clientY, (new Date).getTime(), 3, 1]);
                    var i = t.clientY;
                    e.emit("validate", {
                        left: m(),
                        downY: f,
                        upY: i,
                        track: c
                    }),

这里clientX是距离浏览器左侧的距离，clientY是距离浏览器上侧的距离，clientY一般可以只变一两个像素

0，0的序列实际上不用管，可以写成固定的，至于原因，我也没分析出来，从1，1开始到最后的2，1结束，才是真正滑块移动的轨迹，而且最后一个2，1序列的clientX减去第一个1，1序列的clientX的值，就是参数left的值

最后分析一下加密函数，也就是这里的o.default和u.encrypt

w.on("validate", (function(t) {
    var n = (0,
             u.encrypt)((0,
                         o.default)({}, t, {
        eo: x, //eo的值是前面get请求图片的时候返回
        bss: v, //前面get请求图片的时候返回
        bssKey: g,//固定值
        validateSign: b//前面get请求图片的时候返回
    }));

单步跟一下会发现o.default其实啥也没做，主要是u.encrypt

e.encrypt = function(t) {
    var e = t.left
    , n = t.downY
    , r = t.upY
    , a = t.track
    , s = t.eo
    , c = t.validateSign
    , u = t.bss
    , l = t.bssKey;
    return {
        appKey: 1,
        et: s.et,
        bss: u,
        bssKey: l,
        version: "1.0.1",
        vi: (0,
             o.btoa)((0,
                      i.default)({
            s: 10,
            l: e,
            dy: n,
            uy: r,
            t: a,
            validateSign: c
        }))
    }
}

这里i.default其实就是return r.JSON.stringify.apply(null, arguments) ，也就是把参数给转字符串了，加密函数在o.btoa

e.btoa = function(t) {
    for (var e, n, r = String(t), i = 0, s = o, c = ""; r.charAt(0 | i) || (s = "=",
                                                                            i % 1); c += s.charAt(63 & e >> 8 - i % 1 * 8)) {
        if ((n = r.charCodeAt(i += 3 / 4)) > 255)
            throw new a("'btoa' failed: The string to be encoded contains characters outside of the Latin1 range.");
        e = e << 8 | n
    }
    return c
}

先扣这么一段代码

function encParam(t) {
    for (var e, n, r = String(t), i = 0, s = o, c = ""; r.charAt(0 | i) || (s = "=",
    i % 1); c += s.charAt(63 & e >> 8 - i % 1 * 8)) {
        if ((n = r.charCodeAt(i += 3 / 4)) > 255)
            throw new a("'btoa' failed: The string to be encoded contains characters outside of the Latin1 range.");
        e = e << 8 | n
    }
    return c
}

console.log(encParam('{"s":10,"l":214,"dy":402,"uy":380,"t":[[577,522,1742127604322,0,0],[664,407,1742127604822,0,0],[626,402,1742127605085,1,1],[625,402,1742127605088,2,1],[626,402,1742127605182,2,1],[627,402,1742127605186,2,1],[628,402,1742127605188,2,1],[629,402,1742127605190,2,1],[631,402,1742127605192,2,1],[632,402,1742127605194,2,1],[632,402,1742127605196,2,1],[635,402,1742127605197,2,1],[636,402,1742127605200,2,1],[636,402,1742127605202,2,1],[638,402,1742127605204,2,1],[640,402,1742127605207,2,1],[642,402,1742127605208,2,1],[644,402,1742127605210,2,1],[644,402,1742127605212,2,1],[648,402,1742127605214,2,1],[648,402,1742127605216,2,1],[649,401,1742127605217,2,1],[651,401,1742127605219,2,1],[653,401,1742127605222,2,1],[654,401,1742127605224,2,1],[655,401,1742127605226,2,1],[656,401,1742127605228,2,1],[658,401,1742127605230,2,1],[659,401,1742127605231,2,1],[660,401,1742127605234,2,1],[660,401,1742127605235,2,1],[661,401,1742127605238,2,1],[664,400,1742127605240,2,1],[665,400,1742127605244,2,1],[668,400,1742127605248,2,1],[668,400,1742127605249,2,1],[669,399,1742127605254,2,1],[670,399,1742127605256,2,1],[671,399,1742127605258,2,1],[672,399,1742127605262,2,1]],"validateSign":"AgpkMlZDYW5NV3Z0Cg4xMTUuMTcxLjIxLjEyNBABGgYxNTQzMjI"}'))

参数是在打断点的时候直接得到的

运行的时候报错ReferenceError: o is not defined，o是固定值ABCDEFGHIJKLMNOPQRSTUVWXYZabcdefghijklmnopqrstuvwxyz0123456789+/=

剩下就是分析这里的几个参数是怎么来的了

vi: (0,o.btoa)((0,i.default)({
    s: 10,
    l: e,
    dy: n,
    uy: r,
    t: a,
    validateSign: c
}))

s是固定值，l是向右滑动的距离，dy是鼠标按下的时候距离上端的距离，uy是鼠标松开的时候距离上端的距离，t的话就是伪造就行了

代码

import requests
from base64 import b64decode
import py_mini_racer
import json

url='https://cv.fkw.com/verify/get'
data={"bss":4,
      "bssKey":"ALihhLoGCAEQBBoHWzEsMyw1XSIJ6ZKf55Sz5qC5",
      "appKey":1,
      "version":"1.0.1"}
headers={
    'User-Agent': 'Mozilla/5.0 (Windows NT 10.0; Win64; x64) AppleWebKit/537.36 (KHTML, like Gecko) Chrome/111.0.0.0 Safari/537.36 Edg/111.0.1661.54',
    'Accept': 'application/json'
}
html=requests.post(url,headers=headers,json=data).json()
if html['success']:
    #print(html)
    bs64img=html['msg']['imgId']
    validateSign=html['msg']['validateSign']
    print('validateSign:',validateSign)
else:
    print('请求图片失败，原因如下：',html['msg'])

with open('fkimg.png','wb')as f:
    f.write(b64decode(bs64img))
    print('FK图片保存成功')

def get_vi():
    with open('enc.js','r',encoding='utf8') as f:
        ctx = py_mini_racer.MiniRacer()
        ctx.eval(f.read())
        args = {"s":10,
                "l":214,
                "dy":402,
                "uy":380,
                "t":[[577,522,1742127604322,0,0],[664,407,1742127604822,0,0],[626,402,1742127605085,1,1],[625,402,1742127605088,2,1],[626,402,1742127605182,2,1],[627,402,1742127605186,2,1],[628,402,1742127605188,2,1],[629,402,1742127605190,2,1],[631,402,1742127605192,2,1],[632,402,1742127605194,2,1],[632,402,1742127605196,2,1],[635,402,1742127605197,2,1],[636,402,1742127605200,2,1],[636,402,1742127605202,2,1],[638,402,1742127605204,2,1],[640,402,1742127605207,2,1],[642,402,1742127605208,2,1],[644,402,1742127605210,2,1],[644,402,1742127605212,2,1],[648,402,1742127605214,2,1],[648,402,1742127605216,2,1],[649,401,1742127605217,2,1],[651,401,1742127605219,2,1],[653,401,1742127605222,2,1],[654,401,1742127605224,2,1],[655,401,1742127605226,2,1],[656,401,1742127605228,2,1],[658,401,1742127605230,2,1],[659,401,1742127605231,2,1],[660,401,1742127605234,2,1],[660,401,1742127605235,2,1],[661,401,1742127605238,2,1],[664,400,1742127605240,2,1],[665,400,1742127605244,2,1],[668,400,1742127605248,2,1],[668,400,1742127605249,2,1],[669,399,1742127605254,2,1],[670,399,1742127605256,2,1],[671,399,1742127605258,2,1],[672,399,1742127605262,2,1]],
                "validateSign":validateSign}
        result = ctx.call("encParam",json.dumps(args))
        print("vi的值：",result)
url = 'https://cv.fkw.com/verify/validate'
data = {
    "appkey":1,
    "et":6,
    "bss":4,
    "bssKey":"ALihhLoGCAEQBBoHWzEsMyw1XSIJ6ZKf55Sz5qC5",
    "version":"1.0.1",
    "vi":get_vi()
}
html = requests.get(url,headers=headers,data=data)

轨迹伪造

0，0的序列可以不用管，固定就行，从1，1开始的x坐标，到2，1或者3，1结束的x坐标，两者之差要等于滑动的距离，y的坐标可以不变，x轴的递增可以随机递增，

import random
import time

start_time=int(time.time() * 1000)

def get_time():
    global start_time
    start_time+=random.choice([2,4,6])
    return start_time

def get_random():
    return random.choice([-1,0,1])

def get_trakcs(pos):
    startpos=714
    endpos=pos+startpos
    print(f'startpos:{startpos} endpos:{endpos}')

    tracks=[
            [
                894,
                33,
                get_time(),
                0,
                0
            ],
            [
                731,
                547,
                get_time(),
                0,
                0
            ],
            [
                723,
                535,
                get_time(),
                0,
                0
            ],
            [
                830,
                535,
                get_time(),
                0,
                0
            ]
        ]
	# 因为前面固定了4个0，0序列的轨迹，所以这里滑动的距离如果大于36，就不能直接生成轨迹，不然轨迹序列个数就超过40个了
    # 也就是要控制序列个数不超过40
    if pos < 36:
        random_numbers = [random.randint(startpos, endpos) for _ in range(pos)]
    else:
        random_numbers = [random.randint(startpos, endpos) for _ in range(35)]

    sorted_random_numbers = sorted(random_numbers)
    epoch = 1

    for index,number in enumerate(sorted_random_numbers):
        tracks.append(
            [
                number,
                535+get_random(),
                get_time(),
                epoch,
                1
            ]
        )

        if (index+1)%12==0:
            epoch+=1

    tracks.append(
                [
                    endpos,
                    535+get_random(),
                    get_time(),
                    3,
                    1
                ]
            )
    print("tracks:",tracks)
    print("tracks length:",len(tracks))
    return tracks

if __name__ == '__main__':
    get_trakcs(35)
